Sanitary type butterfly valve for discharging powder and granules


Suitable for containers for pharmaceutical and food plants! Powder and granules discharge valve with excellent cleanability and easy maintenance!


Features


Have excellent cleanability
The main parts are made of stainless steel and have a buffing finish on the inner and outer surfaces, which eliminates the adhesion of powder and granules and provides excellent cleanability.


Easy piping installation, disassembly, and assembly
Lightweight design makes it easy to mount and remove the product from containers and pipes. In addition, the clamp method enables quick disassembly and assembly, making cleaning easier.


Specification

Applicable nominal size (DN)

100 - 300

Valve seat airtight

3kPa

Shell test

0.05MPa

Operating temperature

Room temperature (hot water up to 80°C can be washed)

Connection

Ferrule connection

(DN100~200:ISO/IDF compliant)

(DN250, 300: custom-made)

*Automatic valve: Contact our sales representative for enquiry pneumatically operated ON-OFF valves.
*This valve is applicable only to granular materials (not applicable to liquids).
